Agricultural Bearings: Hex, Square & Round Bore, Seals and Replacement

Series in this line

Click any series concept below. For specific part numbers, dimensions and replacement references, send us your drawing or part number.

Round Bore Insert (KRR Series) ⌄

203KRR2 · 204KRR2 · 205KRR2 · 206KRR2

Most common agricultural insert bearing. Eccentric locking collar, heavy rubber seals. Bore range 5/8" to 1-3/8" (inch) or 17-40mm (metric). For disc harrows, planters, cultivators.

Model	d × D × B (mm)
6201 2RST	12×32×10
203KRR2	16.256×40×18.288
203KRR5	16.256×40×18.288
6203 2RST	17×40×12
Z9504	19.05×45.212×15.494

5 models in this series · Request a quote →

Wide Inner Ring Inserts ⌄

WIR · Pillow block compatible

Extended inner ring for direct mounting on shaft without adapter. Compatible with standard pillow block and flange housings (Pillow blocks UCP/UCF series).

Wide inner ring insert bearings compatible with standard pillow block and flange housings. Send your housing part number. Request a quote →

Tapered Roller Agricultural ⌄

Cone + Cup sets · Trailer hubs

Tapered roller bearings for tractor and implement wheel hubs, trailer axles and heavy-shock-load pivot points. Higher load capacity than ball-type inserts.

Model	d × D × B (mm)
BBY-0076	6.35x31.5
BBY-0083	6.35x31.5
PER.TG21405RRR50	6.477x31.75
3201 ATN9	12×32×15.9
PER.CF5002NYY8	12.7×38.1×19
PER.CF5202RYY	12.7×38.1×15.9
PER.BB204HYY2	17.653x47
PER.CF6901NY	19.05x63.5
PER.CF6901NY-A	19.05x63.5
PER.206RPP16	19.177x62
3204 CE-2RS1TN9/C3	20×47×20.6
6304-2RSH	20×52×15
FYTBK 20 WD	20
PER.FH205-14A	22.225×52×21.5
FYTBK 25 WD	25
PER.FH205A	25×52×21.5
PER.HCN205A	25×52×34.8
PER.UCN205A	25×52×34
YAR 205-2DW/AG	25×52×34.1
YEL 205-2DW/AG	25×52×34.9
PER.FH205-16A	25.4×52×21.5
PER.HC205-16A-A	25.4×52×34.8
YEL 205-100-2DW/AG	25.4×52×34.9
PER.206HPPB5	25.425×62×26.924
PER.206HRR6	25.425×62×24
PER.206HRRB6	25.425×62×24
PER.G206HPPB4	25.425x62
PER.FHR6005-XD-A	27.28×47×28.575
PER.FHR6005-XD-D	27.28×47×38.1
PER.G207HRR28	27.559x78.054

143 models in this series · Request a quote →

Sealed Units (Triple-Lip) ⌄

Triple-lip rubber · Labyrinth

Maximum protection against field contaminants: mud, fertilizer, water, dust. Triple-lip rubber seal or labyrinth non-contact seal options. Grease-packed for life.

Model	d × D × B (mm)
3202 CETN9	15×35×15.9
PER.GW208SPPB6	26.162×80×36.512
PER.W208SPP6	26.162×80×36.512
PER.W208SPPB6	26.162×80×36.512
PER.GW210SPPB4	29.413×90×30.162
PER.W210SPP4-A	29.413×90×30.162
PER.W210SPPB4	29.413×90×30.162
PER.FD209SVVB57	29.972x42.786
PER.GW208SPP17	29.972×85.738×36.512
PER.GW208SPPB5	29.972×80×36.512
PER.GW208SPPB8	29.972×80×36.512
PER.RFD209SVVB50	29.972x42.786
PER.W208SPP5	29.972×80×36.512
PER.W208SPP8	29.972×80×36.512
PER.W208SPPB5	29.972×80×36.512
PER.W208SPPB8	29.972×80×36.512
3206 CE-2RSH1TN9	30×62×23.8
3306 CE-2RSH1TN9	30×72×30.2
3306 CETN9	30×72×30.2
PER.GRNFT206A-A	30
PER.UCNFT206A-A	30
PER.UCNFT206A-B	30
PER.W208RPPB7	30.175×80×30.162
PER.FD209RVVB54	32.258x42.786
PER.GW209SPP8	32.512×85×36.512
PER.GW209SPPB5	32.512×85×36.512
PER.W209SPPB5	32.512×85×36.512
PER.FD209SVVB51	33.02x42.786
3207 CE-2RSH1TN9	35×72×27
3207 CETN9	35×72×27

160 models in this series · Request a quote →

Agricultural Bearing Units ⌄

Seal and bearing units · Hub units

Interchange for agricultural seal and bearing units and hub units, matched by dimensions and function and confirmed on your sample or drawing.

Model	d × D × B (mm)
PER.BB203RRR5	13.061×40×18.288
PER.BB203RYY50	13.081×40×18.288
PER.WBB205RPP62	14.5×53.086×29.15
PER.WP5203NRP2	15.66×30×69
PER.5203NYY50	15.85×40×30.4
AGHU1675X6H-1LLC	16
AGHU1675X6H-1LMB	16
AGHU1675X6H-LC1L	16
AGHU1675X6H-MB1L	16
PER.HUB16-001	16
PER.KITHUB16-001	16
PER.5204RRY2	16.027×45.225×26
PER.BB205RRP2-A	16.03×52×17.983
PER.BB204RRP3	16.053×45.225×18.669
PER.BB204RRY3-D	16.053×45.225×18.669
PER.BB204RRY3-FC-A	16.053
PER.HUB16-005	16.065
PER.5204RRF57-A	16.1×47×22.1
PER.5204RRP50	16.129×47×28
PER.5204RRP51	16.129×47×29.175
PER.BB304RPP50	16.129×53.086×24.608
PER.W5203RYY59	16.129×40×24.5
PER.WBB205RPP60-A	16.129×53.086×19.43
PER.5204RPP55	16.25×47×44.12
PER.5203RPP2-A	16.256×40×44.12
PER.5203RPP54	16.256×40×72
PER.5203RRR2	16.256×40×44.12
PER.5203RSS2	16.256×40×44.12
PER.5203RSS2-A	16.256×40×44.12
PER.5203RYY2	16.256×40×44.12

76 models in this series · Request a quote →

Custom Agricultural ⌄

Drawing-based

Special bore sizes, non-standard seals, custom grease fill for specific OEM equipment. Send your drawing or sample for a custom quote.

Send us your part number or drawing for this series. Request a quote →

Pulley Bearings ⌄

1.001 in OD · 5/16 and 3/8 in bores

Double row, extended inner ring as the spacer, sealed both sides. For mower deck and agricultural idler pulleys.

21 sizes with drawings · View pulley bearings →

75/76 Series Agricultural Bearings ⌄

Outer-ring snap ring

Agricultural bearings with an outer-ring snap ring. Send the complete model or a drawing to confirm the dimensions and ring arrangement.

Send the complete model, drawing or sample. Request a review →

Available options (confirmed per inquiry)

Seal: Triple-lip rubber / Labyrinth
Material: Bearing Steel
Mounting: Eccentric / Concentric collar

Specific configurations are confirmed per quotation. We do not claim every option is in stock for every model — we verify before quoting.

What makes an agricultural bearing different?

Farm equipment combines dust, moisture, crop residue, shock and seasonal maintenance. An agricultural bearing is identified from the shaft interface, locking method, seal package and machine position — not from an abbreviated farm number alone. Round, square and hex bores, extended inner rings and application-specific closures define different products with similar outside dimensions. See the agricultural bearing series guide.

Round, hex or square bore?

Bore form	How the inner ring is driven	Typical use
Round bore	Interference fit, or set screws / eccentric collar on a slip fit	General farm shafts, conveyors, gearbox and hub positions
Hex bore	Positive drive by the hexagonal form on a hex shaft	Planter and drill drive shafts, seed metering, gauge and press wheels, other hex-shaft drives
Square bore	Positive drive by the square form on a square shaft — no set screw or collar to loosen	Disc harrow gangs and similar tillage tools

NLHB supplies 203KRR2-type agricultural bearings. See hex bore vs round bore and disc harrow square-bore bearings.

Seals for mud and water

Most agricultural bearings do not fail from fatigue. They fail because soil, crop residue or water gets past the seal. More contact lips and a flinger exclude more contamination, at the cost of friction and heat; water resistance of the grease matters more than its speed rating. Washing, storage and greasing habits decide whether the seal survives. See why farm bearings get mud and water inside.

Replacing OEM agricultural bearings

A machine maker's part number identifies the part in one catalogue; it does not describe the bearing to another manufacturer. We quote from the measured geometry, bore form, seal and locking method behind that number, cross-referenced by dimensions and function and confirmed on a sample. See replacing OEM agricultural bearings.

What to send for a quotation

Part number and machine position.
Bore form and size (across flats for hex or square), outside diameter and both ring widths.
Seal type and locking method.
A sample or drawing, and the quantity.

Frequently asked questions

Can you replace a bearing from the machine maker's part number?

Yes. We use the part number as a cross-check and quote from the measured dimensions, bore form, seal and locking method, confirmed on a sample.

What is the difference between hex bore and round bore bearings?

A hex bore is driven positively by the hex shaft. A round bore relies on a fit, set screws or an eccentric collar and can creep if the locking fails.

Why do disc harrow bearings have a square bore?

The square gang shaft drives the discs, spools and bearing inner ring as one clamped stack, with no set screw or collar to loosen.

Why do farm bearings fail early?

Usually because soil or water gets past the seal, not from fatigue. Seal design, grease and washing and storage habits decide the life.

Do you make 203KRR2-type bearings?

Yes, NLHB supplies 203KRR2-type agricultural bearings. Bore, seal and ring shape are confirmed against your sample or drawing.
