3800Double-Row Angular Contact Ball Bearings

5001

d 12 × D 28 × B 16 mm

The 5001 is a double-row angular contact ball bearing with bore 12mm, outer diameter 28mm, and width 16mm.

Request Quote for 5001Search Similar
5001 — representative product photo
Representative product
5001 · 12x28x16 mm

📋 Technical Specifications

Bore (d)
12mm
Outer Dia. (D)
28mm
Width (B)
16mm
Dynamic Load (Cr)
Confirm per inquiry(— N)
Static Load (C0r)
Confirm per inquiry(— N)
Reference Speed
Confirm per inquiryrpm
Bearing typeDouble-Row Angular Contact Ball Bearings
Series3800
Seal type2RS (rubber seals) or ZZ (metal shields)
MaterialConfirmed per inquiry — grade and certificate availability reviewed before quotation
Bore typeConfirmed per drawing
Dimension unitmillimeter (mm)

📋 Nominal Variants by Seal Type

Catalog variants open a detail page. Inquiry-only configurations go directly to RFQ.

Seal TypeModel CodeTypical Use
Double metal shields5001 ZZ (inquiry only)General dust protectionQuote →
Double contact rubber seals5001 2RS (inquiry only)Dust and moisture protection at moderate speedQuote →
Double non-contact rubber seals5001 2RZ (inquiry only)Lower-friction sealing at higher speedQuote →
C3 radial clearance5001 C3 (inquiry only)Motors and applications with higher operating temperatureQuote →

📐 Detailed Dimensions

Basic dimensions (mm)

Bore diameter (d)12
Outer diameter (D)28
Width (B)16

Corner radius, shoulder dimensions, fits and tolerances are confirmed against the requested suffix and application drawing before quotation.

📑 Drawings & 3D Model

5001 bearing dimension drawing, 12 x 28 x 16 mm
5001 dimension drawing: bore d 12 mm × outer diameter D 28 mm × width B 16 mm. Tolerance class ABEC-1 (P0). Internal design is shown schematically. Supplied sealed: 2RS (rubber seals) or ZZ (metal shields).
📑
2D Drawing (PDF)
Download PDF →
📐
2D DXF File
Request DXF →
📅
3D STEP Model
Request STEP →

The PDF drawing is free to download. DXF and 3D STEP files are sent on request: tell us the model and your application, and we reply with the CAD files.
